| Quantity: | |
|---|---|
Clear and Transparent
<1
30–65 (Ford Cup #4)
48±2
2-5
TOL/XL/PMA
This resin can air-dry at room temperature or be cured by high-temperature baking, resulting in a fully cured coating film with high hardness and excellent gloss. The coating exhibits outstanding high-temperature resistance, hydrophobicity, and chemical resistance, making it widely used for high-temperature anti-corrosion coatings on boilers, flues, drying ovens, and other metal/non-metal surfaces.
Formulated for the most unforgiving industrial environments, the DS-1066 resin presents itself as a visually pristine, water-white to slightly yellow liquid that is entirely free of mechanical impurities. When applied and fully cured, it undergoes a remarkable transformation, creating an impenetrable, glass-like shield. This resulting paint film feels exceptionally smooth and robust to the touch, reflecting light with a brilliant, high-gloss finish that elevates the visual appeal of any coated surface. The meticulous chemical architecture, utilizing precise ratios of TOL, XL, and BAC as volatile solvents, ensures a flawless application process with optimal flow and leveling characteristics.
Industrial facilities constantly battle the rapid degradation of vital infrastructure caused by relentless heat, moisture, and chemical exposure. By integrating this specialized silicon-modified acrylic resin into your protective coating formulations, you directly address these critical vulnerabilities. The cured barrier exhibits profound mechanical hardness, ensuring that abrasive forces barely leave a scratch, while its inherent hydrophobicity forces corrosive moisture to bead up and roll off instantly. This superior overall performance translates to drastically reduced maintenance cycles and significantly extended lifespans for critical infrastructure, ultimately safeguarding your operational investments and enhancing long-term profitability.
Parameter | Specification |
|---|---|
Appearance | Clear and transparent, free of mechanical impurities. |
Color | Water-white to slightly yellow. |
Viscosity (Ford cup 4, 25℃), seconds | 30-65 |
Solids content (150℃, 1h), % | 46-48 |
Acid value (solution basis, mgKOH/g) | 2-5 |
Glass transition temperature (theoretical value), ℃ | 50 |
Our formulation is meticulously designed to resolve the most persistent challenges faced by industrial coating formulators. By leveraging advanced silicon modification techniques, this resin delivers a synergistic blend of aesthetic brilliance and structural invulnerability.
Uncompromising Surface Hardness: Cures into a dense, impact-resistant layer that withstands severe mechanical stress without fracturing or peeling.
Brilliant Aesthetic Retention: Maintains a luminous, high-gloss appearance even after prolonged exposure to harsh environmental factors, ensuring equipment looks professionally maintained.
Superior Chemical Inertness: Acts as an impermeable barrier against aggressive solvents, acidic vapors, and alkaline spills, preventing underlying substrate degradation.
Optimized Solvent System: The strategic combination of TOL, XL, and BAC solvents ensures excellent solubility, stability, and smooth film formation during the application phase.
The fundamental strength of the DS-1066 resin lies in its extraordinary physical and chemical stability under extreme duress. It is specifically engineered to tackle the core pain points of heavy-duty industrial anti-corrosion coatings.
Extreme Temperature Endurance: Maintains structural integrity and protective capabilities in environments experiencing continuous heat exposure between 250℃ and 450℃.
Advanced Hydrophobic Barrier: The silicon-modified molecular chain repels water at a microscopic level, completely preventing moisture ingress that typically leads to sub-film oxidation.
Flawless Optical Clarity: The clear and transparent nature of the raw resin ensures that it will not negatively interfere with the pigmentation of your final paint formulations.
Predictable Viscosity Control: With a stable Ford cup 4 viscosity of 30-65 seconds at 25℃, formulators can expect consistent manufacturing behavior batch after batch.
We understand that different production facilities operate with varying equipment capabilities and time constraints. This resin is engineered to adapt seamlessly to your specific operational workflows, significantly lowering application barriers.
Ambient Temperature Curing: Perfectly suited for on-site maintenance or facilities lacking large-scale baking ovens, achieving a robust cure simply by air-drying at room temperature.
Accelerated High-Temperature Baking: For high-throughput manufacturing lines, the resin responds exceptionally well to elevated temperature drying, drastically reducing wait times.
Reduced Production Bottlenecks: The dual-curing nature allows production managers to optimize their scheduling, ensuring that coating processes never become the limiting factor in facility output.
Consistent Film Quality: Regardless of the chosen drying method, the final protective layer consistently achieves the targeted hardness, gloss, and chemical resistance.
Targeted specifically for high-stress industrial environments, this resin is the definitive choice for protecting critical infrastructure that operates under punishing thermal and chemical conditions.
Industrial Boilers: Provides a resilient shield for exterior boiler surfaces, preventing thermal oxidation and extending the operational life of the heating units.
Exhaust Flues and Chimneys: Withstands the corrosive combination of high-heat exhaust gases and acidic condensation, maintaining structural integrity over time.
Manufacturing Drying Tunnels: Protects the internal and external metallic components of commercial drying equipment from continuous thermal cycling.
Hot Air Pipelines: Ensures that extensive network piping remains free from external rust and degradation, even when transporting high-temperature gases across facilities.
Versatile Substrate Compatibility: Highly effective on a wide variety of both metallic and non-metallic surfaces requiring heavy-duty thermal protection.
To accelerate your product development cycle and minimize costly trial-and-error phases, our technical engineering team provides comprehensive formulation guidance. Below is a highly stable reference formula for producing a premium high-temperature white anti-corrosion paint.
Base Matrix: DS-1066 Resin (50 parts) provides the core structural and thermal foundation.
Primary Pigmentation: Rutile Titanium Dioxide (20 parts) ensures brilliant opacity and UV resistance.
Performance Fillers: A precise blend of Silica (0.3 parts), Kaolin (5 parts), Iron-Titanium Powder (5 parts), and Barium Sulfate (10 parts) enhances mechanical toughness and barrier properties.
Rheology Modifiers: Bentonite (0.5 parts) prevents pigment settling and ensures smooth application.
Plasticizing Agents: Chlorinated Paraffin (5 parts) adds necessary flexibility to prevent thermal cracking.
Solvent Balance: Mixed Solvents (5 parts) optimize the final application viscosity.
Procurement specialists require absolute certainty regarding the safety, compliance, and consistency of their chemical inputs. We maintain rigorous international standards to ensure every batch meets your exact specifications.
ISO Certification: Our manufacturing facilities operate under strict ISO-certified quality management systems, guaranteeing standardized and repeatable production excellence.
CE Compliance: Meets stringent European health, safety, and environmental protection standards, facilitating smooth entry into highly regulated global markets.
Comprehensive Documentation: Every shipment is accompanied by detailed Certificates of Analysis (COA), providing transparent, batch-specific chemical data.
Safety First: Complete Material Safety Data Sheets (MSDS) are proactively supplied to ensure your handling, storage, and application protocols are completely secure.
As a fully integrated manufacturer with a dedicated export division, we possess the infrastructure and logistical expertise to keep your production lines running without interruption, regardless of your global location.
Rapid Order Processing: Our streamlined production and inventory management systems allow for swift fulfillment, with standard delivery times ranging from just 7 to 15 days.
Flexible Financial Terms: We accommodate diverse procurement requirements by accepting multiple negotiable payment methods, including TT, LC, PayPal, and major credit cards.
Scalable Production Capacity: Whether you require initial testing volumes or massive bulk shipments, our domestic and international supply channels easily scale to meet your demands.
Seamless Global Logistics: Our experienced trade department coordinates complex international freight, ensuring your materials arrive safely, on time, and in pristine condition.
Partnering with the right chemical supplier is a strategic decision that impacts your entire product line. We go beyond mere transactions to build enduring, value-driven relationships with our global clientele.
Direct Manufacturer Advantage: By integrating industry and trade, we eliminate unnecessary intermediaries, offering you highly competitive pricing without compromising on premium quality.
Dedicated Export Expertise: While our roots and main market have long been established in China, our specialized export department is entirely focused on understanding and exceeding the expectations of our international partners.
Unwavering Reliability: We have cultivated numerous robust supply channels, ensuring that supply chain disruptions are mitigated and your material flow remains constant.
Commitment to Reputation: We are deeply invested in building a stellar overseas reputation, which means every order is treated as an opportunity to prove our dedication to your success.
To assist your procurement team in making informed decisions, we have compiled the most critical inquiries regarding our operations and product offerings.
We are a fully integrated Chinese manufacturer. Furthermore, we collaborate strategically with other premium suppliers to seamlessly integrate industry and trade. This extensive network of domestic and international supply channels ensures we can meet the high-volume demands of a diverse global customer base.
While our foundational market has long been the domestic sector in China, we have proactively established a dedicated export department to serve our growing international clientele. We are highly committed to building a strong overseas reputation and forging long-lasting, friendly relationships with foreign customers.
We prioritize financial flexibility for our partners. Our available and fully negotiable payment methods include Telegraphic Transfer (TT), Letter of Credit (LC), PayPal, and major credit cards, ensuring a smooth transaction process tailored to your accounting preferences.
We pride ourselves on operational efficiency. Standard delivery times typically range from 7 to 15 days. However, this timeframe may vary slightly depending on the specific order quantity and the customized requirements of the product you select.
Quality assurance is paramount to our operations. We proudly provide full ISO certification and CE certification to validate our manufacturing standards. Additionally, to support your internal quality control and safety protocols, we supply comprehensive COA (Certificate of Analysis) and MSDS (Material Safety Data Sheet) reports with every shipment.
