| Quantity: | |
|---|---|
Clear and Transparent
<1
Z2-Z5
69±2
4-8
XL/PMA
Specially designed for automotive/motorcycle wheel coatings. Can be used to formulate clear coats, color coats, or metallic (aluminum) paints. Suitable for one-coat applications with excellent adhesion, weather resistance, and salt spray resistance (Xenon lamp 1000h+).
The DS-3016A thermosetting acrylic resin is a meticulously synthesized copolymer of (meth)acrylate monomers and styrene, utilizing xylene and PMA as its primary solvent base. When applied, this transparent, water-white to slightly yellow liquid transforms into a robust, high-gloss protective barrier. The tactile finish is exceptionally smooth, offering a profound sense of fullness that enhances the visual depth of the underlying wheel rim. Designed to withstand the harshest environmental stressors, the cured coating acts as an impenetrable shield against corrosive elements, road debris, and intense ultraviolet degradation.
By facilitating a highly efficient one-coat application, this resin significantly streamlines the finishing process while guaranteeing a flawless, mirror-like surface. The chemical architecture ensures seamless compatibility with various pigments and metallic flakes, making it the definitive choice for formulating premium clear varnishes, vibrant colored paints, and striking silver powder finishes. Its impeccable flow and leveling characteristics eliminate surface defects, resulting in a pristine, factory-grade appearance that elevates the overall value and longevity of the finished vehicle component.
The following technical specifications outline the precise physicochemical properties and operational parameters of our thermosetting acrylic resin. These standardized metrics guarantee consistent performance, seamless integration into your existing formulations, and reliable batch-to-batch quality for all your demanding industrial coating requirements.
Product Name | Thermosetting Acrylic Resin DS-3016A |
|---|---|
Main Composition | Copolymer of (meth)acrylate monomers and styrene |
Solvents | Xylene and PMA |
Appearance | Transparent, free of mechanical impurities |
Color | Water-white to slightly yellow |
Viscosity (Gritter tube, 25℃) | Z2-Z5 seconds |
Solid Content (150℃, 1h) | 69±2 % |
Acid Value (solution) | 4-8 mgKOH/g |
Main Applications | Automotive and motorcycle wheel rim paint, engineering machinery paints |
Compatible Resins | Amino resins (e.g., MR-625), Epoxy (e.g., 601) |
Certifications | ISO, CE, COA, MSDS |
Lead Time | 7 to 15 days |
Payment Terms | TT, LC, PayPal, Credit Cards |
Elevate your production line with a coating solution that merges chemical sophistication with practical application benefits. This thermosetting acrylic resin is engineered to solve common finishing challenges, providing a resilient and visually stunning final product that exceeds stringent industry standards.
Exceptional single-coat coverage that minimizes material usage and application time.
Superior cross-linking density when paired with amino resins, ensuring a rock-solid finish.
Unmatched clarity and gloss retention, preventing yellowing even under prolonged UV exposure.
Highly versatile formulation suitable for clear, colored, and metallic silver powder paints.
Robust resistance to harsh chemicals, road salts, and mechanical abrasions.
Industrial coating lifespans and aesthetic retention are critical metrics for procurement professionals evaluating surface treatments. This acrylic resin is formulated to deliver an uncompromising protective layer that significantly extends the operational life of automotive and motorcycle wheel rims. The high-density polymer network creates an impenetrable barrier against environmental degradation.
Achieves phenomenal adhesion to metallic substrates, preventing peeling, flaking, or delamination under extreme mechanical stress.
Delivers a striking, high-gloss finish with exceptional fullness, enhancing the premium look of the final wheel assembly.
Engineered for extreme weather resistance, maintaining structural and visual integrity through severe temperature fluctuations.
Passes rigorous salt spray testing, enduring over 1000 hours under xenon lamps without compromising its protective qualities.
Acts as a formidable shield against road salt, moisture, and chemical contaminants, drastically reducing corrosion risks.
Maximizing throughput while minimizing overhead is essential for modern coating facilities. This resin is chemically optimized to streamline the application process, directly impacting your bottom line by reducing labor, energy consumption, and cycle times. The formulation is designed to perform flawlessly without the need for complex, multi-step procedures.
Supports a highly efficient one-coat application, eliminating the need for redundant primer or topcoat layers in specific setups.
Accelerates the production cadence, allowing facilities to process larger volumes of wheel rims within tighter timeframes.
Reduces overall material consumption by achieving desired opacity, gloss, and protection in a single pass.
Lowers energy costs associated with prolonged curing cycles, thanks to its optimized thermosetting properties.
Minimizes rework and defect rates through excellent flow and leveling characteristics, ensuring a perfect finish on the first attempt.
Formulation flexibility is a key driver for research and development teams seeking to consolidate their raw material inventory. This versatile resin serves as a foundational building block for a wide array of high-performance coatings, seamlessly adapting to diverse aesthetic and functional requirements across the automotive and heavy machinery sectors.
Specifically tailored for the demanding environment of automotive and motorcycle wheel rim paints.
Flawlessly compatible with various pigment dispersions, making it ideal for formulating deep colored paints and brilliant clear varnishes.
Perfectly suited for suspension with metallic flakes to create striking silver powder paints with excellent orientation.
Demonstrates superior cross-linking compatibility with mainstream amino resins (such as MR-625) and epoxy resins (like 601).
Extends its utility beyond passenger vehicles, offering robust protection for heavy-duty engineering machinery paints.
Maintaining strict batch-to-batch consistency is non-negotiable for large-scale manufacturing. Our quality control protocols ensure that every drum of this thermosetting acrylic resin meets exact physicochemical standards. Technical engineers can rely on these precise metrics to guarantee the stability and high performance of their downstream coating products.
Features a high solid content of 69±2% (at 150℃, 1h), ensuring excellent film build and reduced volatile emissions.
Maintains a low acid value of 4-8 mgKOH/g, promoting stable reactivity and prolonged shelf life of the formulated paint.
Presents a water-white to slightly yellow transparent appearance, guaranteeing no discoloration in clear coat applications.
Strictly filtered to be completely free of mechanical impurities, preventing surface defects and nozzle clogs during spraying.
Controlled viscosity (Z2-Z5 seconds via Gritter tube at 25℃) ensures predictable flow dynamics and consistent application behavior.
Transitioning a new raw material into your production line requires precision and reliable guidance. We provide comprehensive technical backing to minimize your research and development hurdles. By offering proven reference formulas, we empower your laboratory technicians to rapidly prototype, test, and scale up production with absolute confidence.
Direct access to mature, field-tested reference formulas for premium clear varnishes.
Recommended baseline formulation: 64 parts of DS-3016A resin combined with 18-24 parts of MR-625 Amino resin.
Clear guidance on incorporating appropriate amounts of leveling agents and 601 Epoxy for optimized film properties.
Suggested solvent blend utilizing approximately 20 parts of Xylene, Butyl acetate, or Butanol to achieve the perfect application viscosity.
Dedicated technical assistance to help your team fine-tune the formulation to match specific environmental conditions and equipment setups.
A reliable supply chain and strict adherence to international safety standards are the backbone of seamless global procurement. We understand the critical nature of timely deliveries and secure financial transactions. Our robust logistical infrastructure and comprehensive certification portfolio guarantee that your operations remain uninterrupted and fully compliant with global trade regulations.
Expedited lead times of just 7 to 15 days, ensuring your production lines never face material shortages.
Flexible and secure payment terms tailored to your financial requirements, including TT, LC, PayPal, and major credit cards.
Manufactured under strict ISO certification standards, ensuring consistent quality management across all production phases.
Fully CE certified, facilitating smooth customs clearance and regulatory compliance in stringent international markets.
Accompanied by comprehensive COA (Certificate of Analysis) and MSDS (Material Safety Data Sheet) reports for safe handling and auditing.
Partnering with the right manufacturer is a strategic decision that impacts your entire product lifecycle. We integrate advanced chemical engineering with a deep understanding of global market demands. Our commitment goes beyond supplying raw materials; we aim to be an extension of your operational success, providing unparalleled reliability and industry expertise.
Decades of specialized experience in synthesizing high-performance industrial and automotive resins.
A robust integration of manufacturing and trade, offering direct-from-factory pricing without compromising on service.
Extensive domestic and international supply channels capable of fulfilling massive volume requirements with ease.
A newly expanded, dedicated export department focused entirely on the unique needs and communication styles of international clients.
A steadfast commitment to building long-term, mutually beneficial relationships based on trust, exceptional quality, and continuous innovation.
Navigating the technical and logistical aspects of industrial resin procurement requires clear, authoritative answers. Below, we address the most critical inquiries regarding our manufacturing capabilities, product applications, and global shipping processes to help you make an informed sourcing decision.
We operate as a primary manufacturer based in China, while also maintaining strategic collaborations with other specialized suppliers. This integrated approach of industry and trade allows us to offer a comprehensive portfolio and meet the diverse, high-volume demands of our global clientele efficiently.
While we have long been a dominant force in the domestic market, we have actively expanded our global footprint by establishing a dedicated export division. This specialized team is fully equipped to handle international logistics, ensuring our premium products reach overseas facilities with the same reliability we provide locally.
We prioritize financial flexibility to accommodate the diverse procurement policies of our clients. Our accepted payment methods include Telegraphic Transfer (TT), Letter of Credit (LC), PayPal, and major credit cards. All terms are open to negotiation to align with your specific purchasing cycles and financial protocols.
Our streamlined production and logistics networks allow us to maintain a highly aggressive delivery schedule. Standard orders are typically processed and dispatched within 7 to 15 days. This timeline may vary slightly based on the specific order volume and current production queues, but punctuality remains our priority.
Compliance and safety are paramount in our operations. Every shipment is backed by ISO and CE certifications, validating our adherence to international quality and safety standards. Furthermore, we provide detailed Certificates of Analysis (COA) and Material Safety Data Sheets (MSDS) to ensure proper handling and regulatory compliance at your facility.
