Slightly Yellow and Transparent
Z2-Z4
74±2
35-50
IPA/DPM
Neutralized with amine neutralizers and formulated with waterborne amino resins for clear waterborne topcoats on e-bikes and security doors.
The Anti-Corrosion Silicon-Modified Acrylic Resin DS-1066, specifically designated as model A-374, represents a pinnacle in modern aqueous coating technology. When processed, it presents as a visually pristine, light yellow, and entirely transparent viscous liquid, completely devoid of any mechanical impurities. The tactile application experience is exceptionally smooth, gliding seamlessly over metal substrates to form a robust, glass-like protective barrier. Once cured, the resulting paint film exudes a profound fullness and an unmistakable high-gloss sheen that catches the light brilliantly, dramatically elevating the visual appeal of electric vehicles and security doors. Beyond its striking visual characteristics, the cured surface feels remarkably hard to the touch, offering a resilient shield against environmental degradation and aggressive chemical exposure. The sophisticated formulation utilizes ethylene glycol ethyl ether as a solvent, ensuring an optimized drying profile while maintaining excellent water solubility. This advanced copolymer of E-10 and (meth)acrylate monomers fundamentally elevates the standard of waterborne topcoats, providing industrial applicators with a reliable, high-performance medium that resists daily mechanical wear while maintaining its pristine, factory-fresh appearance for years.
Precision and consistency are the fundamental cornerstones of high-volume manufacturing. To guarantee seamless integration into your existing production lines, the Anti-Corrosion Silicon-Modified Acrylic Resin DS-1066 (Model: A-374) is manufactured under the strictest tolerances. Formulators and production managers require absolute predictability in their raw materials to maintain the integrity of their final coatings. The following parameters represent the exact physical and chemical properties you can expect from every single batch delivered to your facility, ensuring that your topcoats consistently meet the highest industry standards for clarity, viscosity, and solid content.
Parameter | Specification |
|---|---|
Product Name | Anti-Corrosion Silicon-Modified Acrylic Resin DS-1066 (Model: A-374) |
Chemical Composition | Copolymer of E-10 and (meth)acrylate monomers |
Solvent | Ethylene glycol ethyl ether |
Appearance | Light yellow and transparent, free of mechanical impurities |
Color | <1 |
Viscosity (Grifler tube, 25℃), seconds | Z-Z2 |
Solid content (150℃, 1h), % | 74±2 |
Acid value (solution, mgKOH/g) | 30-45 |
Upgrading your coating formulations requires materials that do more than just cover a surface; they must actively enhance the end-user's experience while streamlining your internal production processes. The A-374 resin is engineered to solve common application challenges, reducing rework and elevating the final perceived value of the coated product.
Flawless Aesthetic Enhancement: The incredibly low color value ensures that clear varnishes remain perfectly transparent, allowing the true color of the substrate or basecoat to shine through without any yellowing or cloudiness.
Unmatched Structural Defense: The high cross-linking density achieved after curing results in a paint film that feels exceptionally hard, resisting scratches, impacts, and the degrading effects of harsh chemicals.
Superior Workability: The carefully controlled viscosity profile (Z-Z2) ensures that the resin flows smoothly through industrial spray equipment, reducing nozzle clogging and ensuring an even, self-leveling coat.
Maximized Fullness: The impressive solid content guarantees a thick, luxurious build with fewer coats, saving time on the assembly line while providing a premium, deep-gloss finish.
For research and development engineers formulating the next generation of industrial coatings, the foundational metrics of the resin dictate the success of the entire project. The A-374 resin provides a robust and predictable chemical framework designed to meet the most exacting formulation requirements.
Optimized Solid Content: Boasting a high solid content of 74±2%, this resin ensures an exceptional film thickness upon curing. This translates directly to enhanced fullness and a richer visual depth, reducing the total volume of paint required per unit.
Pristine Clarity: With a color index of strictly <1, the resin guarantees absolute transparency in clear topcoats. This is critical for applications where the underlying metallic finish or vibrant solid color must remain entirely uncompromised by the protective layer.
Exceptional Durability Metrics: The specific copolymer structure of E-10 and (meth)acrylate monomers delivers a cured film with extraordinary high gloss, superior surface hardness, and formidable resistance to chemical corrosion, ensuring long-lasting protection in demanding environments.
Understanding the precise operational environment and compatibility matrix of a resin is vital for procurement specialists and production heads. The DS-1066 (A-374) is purposefully tailored for specific, high-stress industrial applications where failure is not an option.
Targeted Industry Applications: This resin is the ideal backbone for topcoats applied to security doors, electric vehicles, and heavy-duty engineering machinery. It withstands the unique environmental stresses these products face daily.
Seamless Resin Integration: It exhibits outstanding compatibility when used in conjunction with (partially) methylated amino resins. This synergy ensures a stable, homogenous mixture that will not separate during storage or application.
Versatile Coating Types: After proper neutralization with an amine neutralizing agent, the A-374 can be effortlessly formulated into both high-clarity water-based varnishes and deeply pigmented solid color paints, offering immense flexibility for your product lines.
We understand that time spent on trial and error in the laboratory is time lost in the market. To support our industrial partners, we provide comprehensive technical backing, including mature, field-tested reference formulations that significantly accelerate your product development cycle and minimize costly formulation mistakes.
A-374: 52
Dimethylethanolamine: 4
Amino 625: 18
Leveling Agent (Digo 425): 0.2
Anti-oil Agent (Digo 500): 0.2
Cosolvent (Ethanol/DPM/BCS=4/3/3): 16
Deionized Water: 10
This precise ratio guarantees excellent workability and optimal curing, allowing your production floor to maintain high throughput with minimal adjustments.
As global regulatory frameworks tighten around volatile organic compounds (VOCs) and hazardous materials, transitioning to compliant raw materials is a strategic imperative. The A-374 resin is designed to future-proof your product offerings while ensuring the safety of your workforce and the environment.
Aqueous Advantage: As a highly effective water-soluble resin, it perfectly aligns with the industry-wide shift from solvent-based to water-based coatings, drastically reducing your factory's overall VOC emissions.
Reduced Toxicity: The formulation minimizes hazardous chemical exposure on the factory floor, creating a safer, more breathable working environment for your application technicians.
Comprehensive Documentation: We supply complete and up-to-date Material Safety Data Sheets (MSDS), ensuring that your logistics, storage, and handling protocols remain entirely compliant with international safety standards.
Risk mitigation is the primary concern for any large-scale procurement operation. Inconsistent raw materials can lead to catastrophic production failures. We eliminate this risk through rigorous, multi-tiered quality assurance protocols and internationally recognized manufacturing certifications.
International Standards: Our production facilities operate under strict ISO certification guidelines, ensuring that every operational process, from raw material sourcing to final packaging, is meticulously controlled and documented.
Global Compliance: The CE certification guarantees that our products meet the stringent health, safety, and environmental protection standards required for international trade and application.
Batch-to-Batch Reliability: We provide a detailed Certificate of Analysis (COA) with every single shipment. We guarantee that the resin is entirely free of mechanical impurities, ensuring your automated spraying equipment remains clean and functional.
A superior product is only valuable if it arrives exactly when your production schedule demands it. We have optimized our entire operational infrastructure to provide agile, reliable, and financially flexible supply chain solutions for our global partners.
Rapid Fulfillment: Leveraging our integrated manufacturing and trading capabilities, we maintain a highly responsive production cycle. Standard delivery times range from a swift 7 to 15 days, heavily dependent on the specific quantity required.
Robust Logistics Network: With numerous domestic and international supply channels, we possess the logistical bandwidth to fulfill the demands of high-volume customers without disruption, even during peak market seasons.
Flexible Financial Terms: We understand the complexities of international cash flow management. Therefore, we offer highly negotiable payment structures, fully supporting TT, LC, PayPal, and major credit cards to suit your specific procurement protocols.
Selecting a raw material supplier is a long-term strategic decision. We do not just provide chemicals; we provide the foundational stability your manufacturing business requires to scale and succeed in a highly competitive global marketplace.
Integrated Expertise: As a Chinese manufacturer that deeply integrates industry and trade, we offer factory-direct insights combined with sophisticated international service standards.
Dedicated Export Focus: Having recently established a specialized export department, our entire infrastructure is now hyper-focused on meeting the exact logistical and communicative needs of our overseas clients.
Long-Term Partnership Mentality: We are committed to building enduring, friendly relationships. Your success in formulating superior electric vehicle and security door coatings is the direct measure of our success as your supplier.
Electric vehicles and security doors face extreme outdoor exposure, requiring topcoats that offer exceptional hardness, high gloss, and robust chemical resistance. The A-374, being a copolymer of E-10 and (meth)acrylate monomers, creates a tightly cross-linked film that perfectly meets these rigorous physical demands while maintaining a visually stunning finish.
A higher solid content means that more of the applied liquid remains on the substrate after the solvent and water evaporate. This allows your applicators to achieve the desired film thickness and fullness with fewer coats, significantly reducing application time, energy costs for curing, and overall material consumption.
Yes, the A-374 is highly versatile. Because its inherent color index is incredibly low (<1), it is perfect for crystal-clear varnishes. However, when neutralized and combined with appropriate pigments and amino resins, it serves as an equally exceptional binder for high-performance solid color paints.
Every shipment is fully documented to ensure seamless integration into your quality control systems. We provide a comprehensive Certificate of Analysis (COA) detailing the exact specifications of your batch, alongside a complete Material Safety Data Sheet (MSDS) for safe handling, supported by our overarching ISO and CE certifications.
Our manufacturing facility employs advanced, multi-stage micro-filtration systems before the final packaging phase. This rigorous process guarantees that the light yellow, transparent liquid you receive is completely devoid of any particulate matter, preventing clogs in your spray nozzles and ensuring a glass-smooth final finish.
